JUKI High-Speed Compact Modular Mounter RS-7
Innovative Production Efficiency
Improvement for the Whole Factory
Features:
• Linking to other machines for improved productivity
• Graphical system visualization
• JaNets Integraton
• New P16S head with improved accuracy
• Simultaneous production of PCBs
• Top and Bottom Check of Leaded Parts
• Low impact placement force
• High speed of maximum cluster tact 75,000 CPH
• Compact Design – 998mm width
• Wide Component Range
Specification:
|
High -Speed Compact Modular Mounter RX-7R |
||||||
|
|
(P16S×P16S head） |
(P16S×P8*1 head) |
(P8×P8*1 head) |
|||
|
Board size |
Single lane conveyer |
50×50～510mm*2*3×450mm |
||||
|
Single lane conveyer |
50×50～510mm*2*3×450mm |
|||||
|
Single lane conveyer |
50×50～510mm*2*3×250mm |
|||||
|
Component height |
3mm |
3mm(P16S head） |
10.5mm |
|||
|
10.5mm（P8 head） |
||||||
|
Component size |
03015*4～□5mm |
03015*4～□5mm |
0603～□25mm |
|||
|
0603～□25mm |
||||||
|
Placement speed |
Chip |
75,000 CPH |
54,900 CPH |
34,800 CPH |
||
|
IC |
- |
6,400 CPH*3 |
12,800 CPH |
|||
|
Placement |
Chip |
±0.04mm(Cpk≧1) |
||||
|
IC |
- |
±0.04mm |
||||
|
Feeder capacity |
Up to 56*6 |
|||||
|
Power supply |
3 phase AC200V、220Ｖ-430V*7 |
|||||
|
|
2.3kVA |
|||||
|
Operating air pressure |
0.5±0.05MPa |
|||||
|
Air consumption (standard) |
20L/分ANR（during normal operation） |
|||||
|
Machine dimensions (W x D xH)*9 |
998×1,895×1,530mm |
998×1,895×1,530mm*8 |
||||
|
Mass (approximately) |
about 1,820kg*10 |
|||||
*1 Contact sales for more details
*2 The BOC, BAD mark, and 2D code can be recognized when the board size X-axis is between 50 mm and 350 mm.
*3 In long board mode.(Two PCBs up to 420mm can be produced simultaneously)
*4 Contact sales for details
*5 Using P8 head
*6 Using RF04AS or RF08AS feeders
*7 Optional transformer required for 220V - 430V
*8 P8 head requires 123mm additional space on the front for the feeder bank
*9 Display and signal light not included
*10 Using P16S x P16S head configuration, dual lane with trolleys
