High Speed Modular JUKI Chip Shooter
❙ Introduce of JUKI Chip Shooter
Cost performance model high-speed JUKI chip shooter, JUKI chip mounting machine, high speed JUKI pick and place machine, for JUKI SMT smart solutions.
■ Chip: 23,500CPH chip (Laser centering/Optimum); 18,500CPH (Laser centering / IPC9850)
■ IC: 9,000CPH (Vision centering/MNVC option)
■ From 0402(01005) to 33.5mm square components
■ One multi-nozzle laser head (6 nozzles)
■ The use of electronic double tape feeders enables mounting of a maximum of 160 component types
■ High-speed, on-the-fly vision centering
(When using both high-resolution camera and MNVC. (option))
■ Longer sized PWB in X axis(option)
❙ Specification of JUKI Chip Shooter
Model | JUKI Chip Shooter KE-3010A | ||
Board Size | M size (330x250 mm) | ||
L size (410x360 mm) | |||
L-Wide size (510x360 mm) *1 | |||
XL size (610x560 mm) | |||
Applicability to long PWB (M size)*2 | 650x250mm | ||
Applicability to long PWB (L size)*2 | 800x360mm | ||
Applicability to long PWB (L-Wide size)*2 | 1,010x360mm | ||
Applicability to long PWB (XL size)*2 | 1,210x560mm | ||
Component height | 6mm | ||
12mm | |||
Component size | Laser recognition | 0402(01005)~□33.5mm | |
Vision recognition | Standard camera |
![]() |
|
High-resolution camera |
![]() |
||
Placement speed | Chip | Optimum | 23,500CPH |
IPC9850 | 18,500CPH | ||
IC*5 |
![]() |
||
Placement accuracy | Laser recognition | ±0.05 mm (±3σ) | |
Vision recognition | ±0.04 mm | ||
Feeder inputs |
Max.160 in case of 8mm tape (on a Electric double tape feeder)*7 |
*1 L-Wide size is optional
